SAVOIR-FAIRE

THE 8 COMPETENCES OF EDOX

Assembled by master watch makers, engineered for champions: for more than 130 years, Edox watches have combined ultimate precision with ingenious solutions – even for the most demanding activities: be it above or below the water surface, in the eternal ice or even on glowing desert sand, any timing instrument from Edox carrying the legendary hourglass logo will meet even the highest demands of its owner. One of the reasons and at the same time one of Edox strength lies in the construction and build quality of our watch cases: from additional case-backs,

ultra-complex cases to patented crown seals and guards, Edox has truly mastered the art of bringing together function and design. Or in other words: engineering a watch case consisting of up to 20 single components is probably the best proof of how serious we are when it comes to accomplishing perfection in every detail. Which means that as an owner of an Edox you will ultimately benefit from more robustness, quality and increased comfort.

1. IN-HOUSE DESIGN



Located in the heart of the Swiss Jura, Edox has been working for years with the same proven team when it comes to designing watches that are equally unique as perfect for their intended use:

  • Instead of a computer-generated design, each watch is first hand drawn for a more organic look
  • Unique style and function-oriented design
  • Ensuring continuity and a highly recognisable product design
  • Exclusive and customised components when it comes to straps, dials and hands

2. ULTRA-COMPLEX CASES



Edox timing instruments are made for performance.
Perfect example: Our complex cases usually consisting of more than just the standard three parts:

  • Expert in case design and engineering
  • Multipart construction with highest precision and attention to detail
  • Increased protection against bumps and water
  • Perfect fusion of design, haptics and function
  • Swiss made quality

3. EXCELLENT MOVEMENTS



We believe in proven movements from the most reputable specialists. Because we want to make absolutely sure that you can rely on your watch every single second of a day – for years to come.

In short:

  • Proven calibres from leading movement suppliers
  • Increased reliability and access to spare parts
  • Excellent quality and longevity
  • Swiss origin

Edox Caliber 07 based on SW 300 Dubois-Dépraz 312

Technical Specifications:

  • Frequency : 28’800 A/h
  • Power Reserve : 40-44 h
  • Diameter : 25.60mm
  • Movement Height : 4.85mm
  • Number of jewels : 25
  • Shock resistance : Incabloc
  • Accuracy margin : 22 s/d
  • Functions : Display of hours, minutes, seconds and date. 24 Time zone display

Edox Caliber 08 based on Dubois-Dépraz 2040

Technical Specifications:

  • Frequency : 28’800 A/h
  • Power Reserve : 38 h
  • Diameter : 25.60mm
  • Movement Height : 7.50mm
  • Number of jewels : 50
  • Shock resistance : Novodiac or Etachocs
  • Accuracy margin : 30 s/d
  • Functions : Display of hours, minutes, seconds, date and chronograph

Edox Caliber 011 based on Valjoux 7750 / SW 500

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power reserve : 46h
  • Diameter: 30.00 MM (13 11/4”’)
  • Movement Height : 7.90MM
  • Number of jewels : 25
  • Shock Resistance : Incabloc
  • Accuracy Margin : 20 s/d
  • Functions : Display of hours, minutes, seconds.

Edox Caliber 30 based on ETA 2892-2 and Dubois-Dépraz 285

Technical Specifications:

  • Frequency : 28’800 A/h
  • Power Reserve: 42h
  • Diameter: 30.00mm
  • Movement Height : 6.50 mm
  • Number of Jewels : 41
  • Shock Resistance : Incabloc
  • Accuracy Margin : 22 s/d
  • Functions : Display of hours, minutes, seconds and date

Edox Caliber 77 based on ETA 2892-A2 / Dubois-Dépraz 14070

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 42h
  • Diameter: 30.00mm (13 1/4”’)
  • Movement Height: 5.20mm
  • Number of Jewels: 25
  • Shock Resistance : Incabloc
  • Accuracy Margin: 22 s/d
  • Functions: Display of hours, minutes, seconds and date, regulator.

Edox Caliber 80 based on ETA 2824 / SW 200

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 38h
  • Diameter: 25.60mm (11 1/2”’)
  • Movement Height: 4.60mm
  • Number of Jewels: 25
  • Shock Resistance : Novodiac or Incabloc
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, seconds and date

Edox Caliber 802 based on SW 200

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 42h
  • Diameter: 25.60mm (11 1/2”’)
  • Movement Height: 3.60mm
  • Number of Jewels: 21
  • Shock Resistance : Novidiac or Etachocs
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, seconds and date

Edox Caliber 805 based on SW 280-1

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 38h
  • Diameter: 25.60mm (11 1/2”’)
  • Movement Height: 5.40mm
  • Number of Jewels: 26
  • Shock Resistance : Novodiac
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, seconds, date and moon phase

Edox Caliber 806 based on SW 200 COSC certified

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 38h
  • Diameter: 25.60mm (11 1/2”’)
  • Movement Height: 3.60mm
  • Number of Jewels: 26
  • Shock Resistance : Incabloc
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, seconds and date

Edox Caliber 82 based on ETA 2004-1

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 40h
  • Diameter: 23.30mm (10 1/2”’)
  • Movement Height: 3.60mm
  • Number of Jewels: 20
  • Shock Resistance : Incabloc
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, seconds and date

Edox Caliber 83 based on ETA 2834

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 42h
  • Diameter: 29.00mm (13”’)
  • Movement Height: 5.50mm
  • Number of Jewels: 25
  • Shock Resistance : Incabloc or Etachoc
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, seconds, day and date

Edox Caliber 85 based on ETA 2824 / SW 200

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 42h
  • Diameter: 25.60mm (11 1/2”’)
  • Movement Height: 4.60mm
  • Number of Jewels: 25
  • Shock Resistance : Novodiac
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, seconds.

Edox Caliber 853 based on SW 200 (semi-skeletonised)

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 38h
  • Diameter: 25.60mm (11 1/2”’)
  • Movement Height: 4.60mm
  • Number of Jewels: 26
  • Shock Resistance : Novodiac
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, seconds.

Edox Caliber 87 based on ETA 2892-A2, Dubois Dépraz DK87

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 42h
  • Diameter: 36.00mm (16”’)
  • Movement Height: 7.35mm
  • Number of Jewels: 21
  • Shock Resistance : Incabloc
  • Accuracy Margin: 22 s/d
  • Functions: 5 minutes repeater. Indication of time by the tone of 2 stricking hammers

Edox Caliber 88 based on SW 220-1

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 38h
  • Diameter: 25.60mm (11 1/2”’)
  • Movement Height: 5.05mm
  • Number of Jewels: 26
  • Shock Resistance : Incabloc
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, seconds day and date

Edox Caliber 91 based on ETA 2824-2 / Dubois Dépraz 291

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 38h
  • Diameter: 30.00mm (13 1/4”’)
  • Movement Height: 7.50mm
  • Number of Jewels: 46
  • Shock Resistance : Incabloc
  • Accuracy Margin: 30 s/d
  • Functions:Display of hours, minutes, date and chronograph

Edox Caliber 94 based on 2892-A2, Soprod 9090

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 42h
  • Diameter: 25.60mm (11 1/2”’)
  • Movement Height: 5.10mm
  • Number of Jewels: 1528
  • Shock Resistance : Incabloc
  • Accuracy Margin: 20 s/d
  • Functions: Display of hours, minutes, seconds, power reserve, big date.

Edox Caliber 95 based on ETA 2894 S2L

Technical Specifications :

  • Frequency : 28’800 A/h
  • Power Reserve: 42h
  • Diameter: 28.00mm (12 1/2”’)
  • Movement Height: 6.00mm
  • Number of Jewels: 37
  • Shock Resistance : Incabloc
  • Accuracy Margin: 30 s/d
  • Functions: Display of hours, minutes, small seconds

4. ULTIMATE PRECISION



When it comes to precision we are convinced that being as strict and meticulous as possible is well worth it. Because you will appreciate the quality and attention to detail:

  • All hands are designed and made in Switzerland and produced exclusively made-to-measure
  • The manufacturing tolerance is 1/100 millimetre
  • No standard components are used

5. HANDMADE MASTERPIECES



Every single part of an Edox watch is made to exact specifications with the lowest possible fabrication tolerances. Nevertheless: Assembly and regulation are still done by hand by skilled watchmakers.

  • One watchmaker is responsible for the whole watch  during   assembly and regulation
  • Production and quality control are strictly separated
  • Continuing training and education of our staff
  • State-of-the-art manufacturing processes and tools

6. TIME FOR INNOVATION



Edox has a long tradition of finding smart solutions for complex challenges, such as:

  • Patented double sealed crown (without requiring a screw-in construction) for increased water resistance
  • Added protection against shocks for the movement
  • Ultra-flat movements for maximum elegance

8. MADE FOR CHAMPIONS



Edox is proud to be chosen as official timekeeper of various competitions and races around the globe. And as a result of this, many athletes and explorers are relying on the quality of their Edox watches as we have

  • Long tradition as official timekeeper in automobile racing
  • Expert for diving and sailing
  • Proven quality even in the most harsh conditions
